Create Transparent Image of Excel Worksheet with JavaScript via C++

Sometimes, you need to generate the image of your worksheet as a transparent image. You want to apply transparency to all cells which have no fill colors. Aspose.Cells provides the ImageOrPrintOptions.transparent property to apply transparency to the worksheet image. When this property is false, then cells with no fill colors are drawn with white color and when it is true, cells with no fill colors are drawn transparent.

In the following worksheet image, transparency has not been applied. The cells with no fill colors are drawn white.

Output without transparency: the cell background is white

While, in the following worksheet image, transparency has been applied. The cells with no fill colors are transparent.

Output with transparency enabled

The following sample code generates a transparent image from an Excel worksheet.

<!DOCTYPE html>
<html>
    <head>
        <title>Aspose.Cells Create Transparent Image Example</title>
    </head>
    <body>
        <h1>Create Transparent Image Example</h1>
        <input type="file" id="fileInput" accept=".xls,.xlsx,.xlsm,.csv" />
        <button id="runExample">Create Transparent PNG</button>
        <a id="downloadLink" style="display: none;">Download Result</a>
        <div id="result"></div>
    </body>

    <script src="aspose.cells.js.min.js"></script>
    <script type="text/javascript">
        const { Workbook, ImageOrPrintOptions, SheetRender, ImageType } = AsposeCells;

        AsposeCells.onReady({
            license: "/lic/aspose.cells.enc",
            fontPath: "/fonts/",
            fontList: [
                "arial.ttf",
                "NotoSansSC-Regular.ttf"
            ]
        }).then(() => {
            console.log("Aspose.Cells initialized");
        });

        document.getElementById('runExample').addEventListener('click', async () => {
            const fileInput = document.getElementById('fileInput');
            if (!fileInput.files.length) {
                document.getElementById('result').innerHTML = '<p style="color: red;">Please select an Excel file.</p>';
                return;
            }

            const file = fileInput.files[0];
            const arrayBuffer = await file.arrayBuffer();

            // Create workbook object from uploaded file
            const wb = new Workbook(new Uint8Array(arrayBuffer));

            // Access first worksheet
            const sheet = wb.worksheets.get(0);

            // Apply different image or print options
            const imgOption = new ImageOrPrintOptions();
            imgOption.imageType = ImageType.Png;
            imgOption.horizontalResolution = 200;
            imgOption.verticalResolution = 200;
            imgOption.onePagePerSheet = true;

            // Apply transparency to the output image
            imgOption.transparent = true;

            // Create image after applying image or print options
            const sr = new SheetRender(sheet, imgOption);
            const outputData = await sr.toImage(0);

            const blob = new Blob([outputData], { type: 'image/png' });
            const downloadLink = document.getElementById('downloadLink');
            downloadLink.href = URL.createObjectURL(blob);
            downloadLink.download = 'outputCreateTransparentImage.png';
            downloadLink.style.display = 'block';
            downloadLink.textContent = 'Download PNG Image';

            document.getElementById('result').innerHTML = '<p style="color: green;">Image created successfully! Click the download link to get the PNG file.</p>';
        });
    </script>
</html>
