Create Image Stencils in Python

Quick Answer: To create an image stencil or black-and-white vectorization result in Python, configure ImageVectorizer with BezierPathBuilder and StencilConfiguration, set the stencil type and output color, call vectorize(input_path), and save the returned SVGDocument as an SVG file.

An image stencil is a simplified vector version of a raster image. Instead of preserving every color and detail, stencil output focuses on clean shapes, outlines, or limited-color regions that can be used for design, print, cutting, templates, and stylized artwork.

When to Use Image Stenciling

Use image stenciling when the final SVG should be intentionally simplified. It is a good fit for artwork that needs strong contours, limited colors, or a single-color graphic style. Logos, icons, signs, line drawings, and high-contrast illustrations usually produce cleaner stencils than noisy photos.

If you want to preserve more source colors and details, use normal image vectorization instead.

Create Image Stencil in Python

The following example turns tulip.png into a stencil-style SVG. It configures smoothing and path approximation, limits the color count used during vectorization, and applies StencilConfiguration with StencilType.AUTO so the vectorizer can choose the stencil behavior and colors automatically.

import os
from aspose.svg.drawing import Color
from aspose.svg.imagevectorization import (
    BezierPathBuilder,
    ImageTraceSmoother,
    ImageVectorizer,
    StencilConfiguration,
    StencilType,
)

# Create an SVG stencil from a raster image using automatic stencil mode
input_folder = "data/"
output_folder = "output/"
input_path = os.path.join(input_folder, "tulip.png")
output_path = os.path.join(output_folder, "tulip-stencil.svg")
os.makedirs(output_folder, exist_ok=True)

path_builder = BezierPathBuilder()
path_builder.trace_smoother = ImageTraceSmoother(3)
path_builder.error_threshold = 20.0
path_builder.max_iterations = 15

vectorizer = ImageVectorizer()
vectorizer.configuration.path_builder = path_builder
vectorizer.configuration.colors_limit = 15
vectorizer.configuration.line_width = 1.0

stencil_config = StencilConfiguration()
stencil_config.type = StencilType.AUTO
vectorizer.configuration.stencil = stencil_config

with vectorizer.vectorize(input_path) as document:
    document.save(output_path)

The generated tulip-stencil.svg contains simplified vector geometry with colors selected automatically by StencilType.AUTO. This makes the example useful for showing a general stencil effect before the stricter black-and-white workflow below.

The illustration compares the raster tulip image (a) with the automatically generated color stencil result (b).

Create a Black-and-White SVG Stencil in Python

Black-and-white vectorization is a stencil workflow where the output intentionally uses one foreground color on a plain background instead of preserving the source palette. Use it for cutting templates, printable outlines, icons, signs, craft artwork, and high-contrast graphics.

The example below turns logo.png into a black stencil SVG. It uses StencilConfiguration with StencilType.MONO_COLOR, sets the stencil color to black, and keeps the color limit low so the source is simplified before the stencil effect is applied.

import os
from aspose.svg.drawing import Color
from aspose.svg.imagevectorization import (
    BezierPathBuilder,
    ImageTraceSmoother,
    ImageVectorizer,
    StencilConfiguration,
    StencilType,
)

# Create a black-and-white SVG stencil from a raster logo
input_folder = "data/"
output_folder = "output/"
input_path = os.path.join(input_folder, "logo.png")
output_path = os.path.join(output_folder, "logo-black-white-stencil.svg")
os.makedirs(output_folder, exist_ok=True)

path_builder = BezierPathBuilder()
path_builder.trace_smoother = ImageTraceSmoother(2)
path_builder.error_threshold = 12.0
path_builder.max_iterations = 15

vectorizer = ImageVectorizer()
vectorizer.configuration.path_builder = path_builder
vectorizer.configuration.colors_limit = 2
vectorizer.configuration.line_width = 1.5

stencil_config = StencilConfiguration()
stencil_config.type = StencilType.MONO_COLOR
stencil_config.color = Color.from_rgb(0, 0, 0)
vectorizer.configuration.stencil = stencil_config

with vectorizer.vectorize(input_path) as document:
    document.save(output_path)

If the black-and-white stencil loses important shapes, reduce smoothing or lower error_threshold. If the output contains too many small fragments, simplify the input image first or increase smoothing slightly.

The illustration below shows how a flat raster logo is simplified into a high-contrast black-and-white SVG stencil.

Note: StencilType.MONO_COLOR is not limited to black. Choose the foreground color in the line stencil_config.color = Color.from_rgb(0, 0, 0), for example by using RGB values for blue, red, green, or a brand color.

Stencil vs Multicolor Vectorization

Stencil output and normal image vectorization solve different problems. Normal multicolor vectorization tries to preserve visible color regions from the source image. A stencil intentionally discards most color information and produces simplified shapes that are easier to print, cut, trace, or reuse as monochrome artwork.

Workflow	Output style	Best for
Normal image vectorization	Multiple color regions and paths	Illustrations, logos, diagrams, and SVG approximations of raster artwork
Black-and-white stencil	One foreground color with simplified shapes	Cutting templates, signs, icons, print masks, craft designs, and high-contrast artwork
Limited-color stencil	A simplified stencil look with a chosen output color	Branded stencil artwork, previews, and stylized design assets

Aspose.SVG APIs Used

API	Purpose
ImageVectorizer	Converts the raster source to an SVG document
ImageVectorizerConfiguration	Stores vectorization and stencil settings
BezierPathBuilder	Builds vector paths from traced contours
ImageTraceSmoother	Smooths traced contours before path construction
StencilConfiguration	Configures stencil output
StencilType	Defines the stencil mode
Color	Sets the stencil color

Stencil Settings That Affect Output

Setting	Effect	Practical guidance
stencil_config.type	Selects the stencil mode	Use StencilType.AUTO for a general stencil result and StencilType.MONO_COLOR for one-color output
stencil_config.color	Sets the output color for mono-color stencil mode	Pick a high-contrast color when using StencilType.MONO_COLOR
colors_limit	Controls color quantization before stencil output	Lower values simplify the source and usually produce cleaner stencil shapes
trace_smoother	Smooths contour fragments	Increase it to reduce jagged edges, but check small details
error_threshold	Controls path approximation tolerance	Lower values preserve more detail; higher values simplify paths
line_width	Sets the generated line width	Adjust it to match the target visual scale

Common Mistakes and Fixes

Problem	Likely cause	Fix
Stencil has too much detail	Source image is noisy or colors_limit is too high	Preprocess the source, reduce colors, or increase smoothing
Important shapes disappear	Simplification is too aggressive	Lower smoothing or reduce error_threshold
Output looks jagged	Contours were traced with too little smoothing	Increase trace_smoother and inspect the SVG at the target size
Photo output is complex	Continuous-tone photos are difficult to simplify cleanly	Use high-contrast artwork or reduce the photo before vectorization
