Use Custom XML Parts in Aspose.Cells with Node.js via C++

Using Custom XML Parts in Aspose.Cells

Custom XML Parts are XML data stored by various applications such as SharePoint inside an Excel file. This data is consumed by applications that need it. Microsoft Excel does not use this data, so there is no GUI to add it. You can view this data by changing the extension of an .xlsx file to .zip and then opening it with WinZip. You can also open the ZIP file using any third‑party Windows zip utility such as WinRAR or WinZip. The data is present inside the customXml folder.

You can add custom XML parts using Aspose.Cells via the ContentTypePropertyCollection method.

The following sample code uses the ContentTypePropertyCollection method to add the Book Catalog XML, naming it BookStore. The following image shows the result of this code. As you can see, the Book Catalog XML is added inside the BookStore node, which is the name of this property.

Node.js code to use custom XML parts

const path = require("path");
const AsposeCells = require("aspose.cells.node");

// The path to the documents directory.
const dataDir = path.join(__dirname, "data");
const filePath = path.join(dataDir, "output.xlsx");

// The sample XML that will be injected to Workbook
const booksXML = `<catalog>
<book>
<title>Complete C#</title>
<price>44</price>
</book>
<book>
<title>Complete Java</title>
<price>76</price>
</book>
<book>
<title>Complete SharePoint</title>
<price>55</price>
</book>
<book>
<title>Complete PHP</title>
<price>63</price>
</book>
<book>
<title>Complete VB.NET</title>
<price>72</price>
</book>
</catalog>`;

// Create an instance of Workbook class
const workbook = new AsposeCells.Workbook();

// Add Custom XML Part to ContentTypePropertyCollection
workbook.getContentTypeProperties().add("BookStore", booksXML);

// Save the resultant spreadsheet
workbook.save(filePath);
