将 HTML 转换为 PDF(.NET)

概述

本文档说明如何 使用 C# 将 HTML 转换为 PDF。它涵盖以下主题。

以下代码片段同样适用于 Aspose.PDF.Drawing 库。

Aspose.PDF for .NET 是一套 PDF 操作 API,能够无缝将任意现有 HTML 文档转换为 PDF。HTML 转 PDF 的过程可以灵活定制。

将 HTML 转换为 PDF

以下 C# 示例代码展示了如何将 HTML 文档转换为 PDF。

将 HTML 转换为 PDF

  1. 创建 HtmlLoadOptions 类的实例。
  2. 初始化 Document 对象。
  3. 调用 Document.Save() 方法保存输出的 PDF 文档。
// For complete examples and data files, visit https://github.com/aspose-pdf/Aspose.PDF-for-.NET
private static void ConvertHTMLtoPDF()
{
    // The path to the documents directory
    var dataDir = RunExamples.GetDataDir_AsposePdf();

    // Load the HTML file into a document using HtmlLoadOptions
    var options = new Aspose.Pdf.HtmlLoadOptions();

    // Open HTML document
    using (var document = new Aspose.Pdf.Document(dataDir + "test.html", options))
    {
        // Save PDF document
        document.Save(dataDir + "ConvertHTMLtoPDF_out.pdf");
    }
}

高级 HTML 转 PDF 转换

HTML 转换引擎提供了多种选项,帮助我们控制转换过程。

媒体查询支持

媒体查询是一种流行技术,用于向不同设备提供定制的样式表。我们可以使用 HtmlMediaType 属性设置设备类型。

// For complete examples and data files, visit https://github.com/aspose-pdf/Aspose.PDF-for-.NET
private static void ConvertHTMLtoPDFAdvancedMediaType()
{
    // The path to the documents directory
    var dataDir = RunExamples.GetDataDir_AsposePdf();

    // Load the HTML file into a document using HtmlLoadOptions with Print media type
    var options = new HtmlLoadOptions
    {
        // Set Print or Screen mode
        HtmlMediaType = Aspose.Pdf.HtmlMediaType.Print
    };

    // Open HTML document
    using (var document = new Aspose.Pdf.Document(dataDir + "test.html", options))
    {
        // Save PDF document
        document.Save(dataDir + "ConvertHTMLtoPDFAdvancedMediaType_out.pdf");
    }
}

启用(禁用)字体嵌入

HTML 页面常常使用字体(例如本地文件夹中的字体、Google Fonts 等)。我们也可以通过 IsEmbedFonts 属性控制文档中字体的嵌入。

 // For complete examples and data files, visit https://github.com/aspose-pdf/Aspose.PDF-for-.NET
 private static void ConvertHTMLtoPDFAdvancedEmbedFonts()
 {
     // The path to the documents directory
     var dataDir = RunExamples.GetDataDir_AsposePdf();

     // Load the HTML file into a document using HtmlLoadOptions with the font embedding option set
     var options = new Aspose.Pdf.HtmlLoadOptions
     {
         // Disable font embedding
         IsEmbedFonts = false
     };

     // Open HTML document
     using (var document = new Aspose.Pdf.Document(dataDir + "test_fonts.html", options))
     {
         // Save PDF document
         document.Save(dataDir + "ConvertHTMLtoPDFAdvanced_EmbedFonts_out.pdf");
     }
 }

管理外部资源加载

转换引擎提供了一种机制,允许您控制与 HTML 文档关联的某些资源的加载。
HtmlLoadOptions 类拥有属性 CustomLoaderOfExternalResources,可用于定义资源加载器的行为。
假设我们需要将所有 PNG 图像替换为单个图像 test.jpg,并将外部 URL 替换为内部资源的 URL。
为此我们可以定义自定义加载器 SamePictureLoader,并将 CustomLoaderOfExternalResources 指向该名称。

// For complete examples and data files, visit https://github.com/aspose-pdf/Aspose.PDF-for-.NET
private static void ConvertHTMLtoPDFAdvanced_DummyImage()
{
    // The path to the documents directory
    var dataDir = RunExamples.GetDataDir_AsposePdf();

    // Load the HTML file into a document with a custom resource loader for external images
    var options = new Aspose.Pdf.HtmlLoadOptions
    {
        CustomLoaderOfExternalResources = SamePictureLoader
    };

    // Open HTML document
    using (var document = new Aspose.Pdf.Document(dataDir + "test.html", options))
    {
        // Save PDF document
        document.Save(dataDir + "html_test.pdf");
    }
}

private static Aspose.Pdf.LoadOptions.ResourceLoadingResult SamePictureLoader(string resourceURI)
{
    // The path to the documents directory
    var dataDir = RunExamples.GetDataDir_AsposePdf();
    Aspose.Pdf.LoadOptions.ResourceLoadingResult result;

    if (resourceURI.EndsWith(".png"))
    {
        byte[] resultBytes = File.ReadAllBytes(dataDir + "test.jpg");
        result = new Aspose.Pdf.LoadOptions.ResourceLoadingResult(resultBytes)
        {
            // Set MIME Type
            MIMETypeIfKnown = "image/jpeg"
        };
    }
    else
    {
        result = new Aspose.Pdf.LoadOptions.ResourceLoadingResult(GetContentFromUrl(resourceURI));
    }
    return result;
}

private static byte[] GetContentFromUrl(string url)
{
    var httpClient = new System.Net.Http.HttpClient();
    return httpClient.GetByteArrayAsync(url).GetAwaiter().GetResult();
}

在单页中渲染所有 HTML 内容

Aspose.PDF for .NET 提供了在将 HTML 文件转换为 PDF 格式时将所有内容渲染到单页的能力。例如,当 HTML 内容的输出尺寸超过一页时,您可以使用此选项将输出数据渲染到单个 PDF 页面。为启用此选项,HtmlLoadOptions 类新增了 IsRenderToSinglePage 标志。下面的代码片段展示了如何使用此功能。

 // For complete examples and data files, visit https://github.com/aspose-pdf/Aspose.PDF-for-.NET
 private static void ConvertHTMLtoPDFAdvancedSinglePageRendering()
 {
     // The path to the documents directory
     var dataDir = RunExamples.GetDataDir_AsposePdf();

     // Initialize HtmlLoadOptions
     var options = new Aspose.Pdf.HtmlLoadOptions
     {
         // Set Render to single page property
         IsRenderToSinglePage = true
     };

     // Open PDF document
     using (var document = new Aspose.Pdf.Document(dataDir + "HTMLToPDF.html", options))
     {
         // Save PDF document
         document.Save(dataDir + "RenderContentToSamePage_out.pdf");
     }
 }

使用 SVG 数据渲染 HTML

Aspose.PDF for .NET 能够将 HTML 页面转换为 PDF 文档。由于 HTML 允许在页面中以标签形式添加 SVG 图形元素,Aspose.PDF 也支持将此类数据转换为生成的 PDF 文件。以下代码片段展示了如何将包含 SVG 图形标签的 HTML 文件转换为带标签的 PDF 文档。

// For complete examples and data files, visit https://github.com/aspose-pdf/Aspose.PDF-for-.NET
private static void ConvertHTMLtoPDFWithSVG()
{
    // The path to the documents directory
    var dataDir = RunExamples.GetDataDir_AsposePdf();

    // Initialize HtmlLoadOptions
    var options = new Aspose.Pdf.HtmlLoadOptions(Path.GetDirectoryName(dataDir + "HTMLSVG.html"));

    // Initialize Document object
    using (var document = new Aspose.Pdf.Document(dataDir + "HTMLSVG.html", options))
    {
        // Save PDF document
        document.Save(dataDir + "RenderHTMLwithSVGData_out.pdf");
    }
}

从 HTML 标签创建逻辑结构

为了满足可访问性要求,PDF 文档应包含定义阅读顺序的逻辑结构元素,为屏幕阅读器提供替代文本以描述文档的插图部分,并标记内容层次结构。

许多 HTML 文档已经包含此类逻辑结构。Aspose.PDF 可以在 HTML‑to‑PDF 转换过程中保留并转移这些结构到 PDF。

将 HtmlLoadOptions.CreateLogicalStructure 属性设为 true,即可使用 PDF 逻辑结构元素复制原始 HTML 文档的结构。

将网页转换为 PDF

将网页转换为 PDF 与转换本地 HTML 文档略有不同。为了将网页内容转换为 PDF 格式,我们可以先使用 HttpClient 实例获取 HTML 页面内容,创建 Stream 对象,将内容传递给 Document 对象并渲染为 PDF。

在将托管于 Web 服务器的网页转换为 PDF 时:

将网页转换为 PDF

  1. 使用 HttpClient 对象读取页面内容。
  2. 实例化 HtmlLoadOptions 对象并设置基准 URL。
  3. 在传入流对象的同时初始化 Document 对象。
  4. (可选)设置页面尺寸和/或方向。
// For complete examples and data files, visit https://github.com/aspose-pdf/Aspose.PDF-for-.NET
private static void ConvertHTMLtoPDFAdvanced_WebPage()
{
    // The path to the documents directory
    var dataDir = RunExamples.GetDataDir_AsposePdf();

    const string url = "https://en.wikipedia.org/wiki/Aspose_API";

    // Set page size A3 and Landscape orientation;
    var options = new Aspose.Pdf.HtmlLoadOptions(url)
    {
        PageInfo =
        {
            Width = 842,
            Height = 1191,
            IsLandscape = true
        }
    };

    // Load the web page content as a stream and create a PDF document
    using (var document = new Aspose.Pdf.Document(GetContentFromUrlAsStream(url), options))
    {
        // Save PDF document
        document.Save(dataDir + "html_test.pdf");
    }
}

private static Stream GetContentFromUrlAsStream(string url, System.Net.ICredentials credentials = null)
{
    using (var handler = new System.Net.Http.HttpClientHandler { Credentials = credentials })
    using (var httpClient = new System.Net.Http.HttpClient(handler))
    {
        return httpClient.GetStreamAsync(url).GetAwaiter().GetResult();
    }
}

为网页转 PDF 提供凭据

有时我们需要转换需要身份验证和访问权限的 HTML 文件,以便只有授权用户才能获取页面内容。这也包括 HTML 中引用的某些资源/数据需要从要求身份验证的外部服务器获取的场景。为满足此需求,ExternalResourcesCredentials 属性已添加到 HtmlLoadOptions 类中。下面的代码片段展示了在将 HTML 文件转换为 PDF 时传递凭据以请求 HTML 及其相应资源的步骤。

 // For complete examples and data files, visit https://github.com/aspose-pdf/Aspose.PDF-for-.NET
 private static void ConvertHTMLtoPDFAdvancedAuthorized()
 {
     // The path to the documents directory
     var dataDir = RunExamples.GetDataDir_AsposePdf();

     const string url = "http://httpbin.org/basic-auth/user1/password1";
     var credentials = new System.Net.NetworkCredential("user1", "password1");

     var options = new Aspose.Pdf.HtmlLoadOptions(url)
     {
         ExternalResourcesCredentials = credentials
     };

     using (var document = new Aspose.Pdf.Document(GetContentFromUrlAsStream(url, credentials), options))
     {
         // Save PDF document
         document.Save(dataDir + "HtmlTest_out.pdf");
     }
 }

private static Stream GetContentFromUrlAsStream(string url, System.Net.ICredentials credentials = null)
{
    using (var handler = new System.Net.Http.HttpClientHandler { Credentials = credentials })
    using (var httpClient = new System.Net.Http.HttpClient(handler))
    {
        return httpClient.GetStreamAsync(url).GetAwaiter().GetResult();
    }
}

将 MHTML 转换为 PDF

MHTML,即 MIME HTML,是一种网页归档格式,用于将通常通过外部链接(如图像、Flash 动画、Java 小程序和音频文件)表示的资源与 HTML 代码合并为单个文件。MHTML 文件的内容被编码为类似 HTML 电子邮件的 MIME 类型 multipart/related。Aspose.PDF for .NET 能将 HTML 文件转换为 PDF 格式,并且在 Aspose.PDF for .NET 9.0.0 版本中,我们引入了将 MHTML 文件转换为 PDF 格式的新功能。下面的代码片段展示了如何使用 C# 将 MHTML 文件转换为 PDF 格式:

将 MHTML 转换为 PDF

  1. 创建 MhtLoadOptions 类的实例。
  2. 初始化 Document 对象。
  3. 调用 Document.Save() 方法保存输出的 PDF 文档。
// For complete examples and data files, visit https://github.com/aspose-pdf/Aspose.PDF-for-.NET
private static void ConvertMHTtoPDF()
{
    // The path to the documents directory
    var dataDir = RunExamples.GetDataDir_AsposePdf();

    // Initialize MhtLoadOptions with page setup
    var options = new Aspose.Pdf.MhtLoadOptions()
    {
        PageInfo = { Width = 842, Height = 1191, IsLandscape = true }
    };

    // Initialize Document object using the MHT file and options
    using (var document = new Aspose.Pdf.Document(dataDir + "fileformatinfo.mht", options))
    {
        // Save PDF document
        document.Save(dataDir + "MhtmlTest_out.pdf");
    }
}
