Manage Rows and Columns

To allow you to manage a table’s rows and columns in a PowerPoint presentation, Aspose.Slides provides the Table class, ITable interface, and many other types.

Set First Row as Header

  1. Create an instance of the Presentation class and load the presentation.
  2. Get a slide’s reference through its index.
  3. Create an ITable object and set it to null.
  4. Iterate through all IShape objects to find the relevant table.
  5. Set the table’s first row as its header.

This C++ code shows you how to set a table’s first row as its header:

// Instantiates the Presentation class
auto pres = System::MakeObject<Presentation>(u"table.pptx");

// Accesses the first slide
auto sld = pres->get_Slides()->idx_get(0);

// Initializes the null TableEx
SharedPtr<ITable> tbl;

// Iterates through the shapes and sets a reference to the table
for (const auto& shp : sld->get_Shapes())
{
    if (ObjectExt::Is<ITable>(shp))
    {
        tbl = System::ExplicitCast<ITable>(shp);
    }
}

// Sets the first row of a table its header
tbl->set_FirstRow(true);

Clone Table’s Row or Column

  1. Create an instance of the Presentation class and load the presentation,
  2. Get a slide’s reference through its index.
  3. Define an array of columnWidth.
  4. Define an array of rowHeight.
  5. Add an ITable object to the slide through the AddTable() method.
  6. Clone the table row.
  7. Clone the table column.
  8. Save the modified presentation.

This C++ code shows you how to clone a PowerPoint table’s row or column:

 // The path to the documents directory.
const String outPath = u"../out/CloningInTable_out.pptx";

// Instantiates the Presentation class
SharedPtr<Presentation> pres = MakeObject<Presentation>();

// Accesses the first slide
SharedPtr<ISlide> islide = pres->get_Slides()->idx_get(0);

// Defines columns with widths and rows with heights
System::ArrayPtr<double> dblCols = System::MakeObject<System::Array<double>>(4, 70);
System::ArrayPtr<double> dblRows = System::MakeObject<System::Array<double>>(4, 70);

// Adds a table shape to the slide
SharedPtr<ITable> table = islide->get_Shapes()->AddTable(100, 50, dblCols, dblRows);


// Sets the border format for each cell
for (int x = 0; x < table->get_Rows()->get_Count(); x++)
{
	SharedPtr<IRow> row = table->get_Rows()->idx_get(x);
	for (int y = 0; y < row->get_Count(); y++)
	{
		SharedPtr<ICell> cell = row->idx_get(y);

		cell->get_BorderTop()->get_FillFormat()->set_FillType(FillType::Solid);
		cell->get_BorderTop()->get_FillFormat()->get_SolidFillColor()->set_Color(System::Drawing::Color::get_Red());
		cell->get_BorderTop()->set_Width(5);

		cell->get_BorderBottom()->get_FillFormat()->set_FillType(FillType::Solid);
		cell->get_BorderBottom()->get_FillFormat()->get_SolidFillColor()->set_Color(System::Drawing::Color::get_Red());
		cell->get_BorderBottom()->set_Width(5);

		cell->get_BorderLeft()->get_FillFormat()->set_FillType(FillType::Solid);
		cell->get_BorderLeft()->get_FillFormat()->get_SolidFillColor()->set_Color(System::Drawing::Color::get_Red());
		cell->get_BorderLeft()->set_Width(5);

		cell->get_BorderRight()->get_FillFormat()->set_FillType(FillType::Solid);
		cell->get_BorderRight()->get_FillFormat()->get_SolidFillColor()->set_Color(System::Drawing::Color::get_Red());
		cell->get_BorderRight()->set_Width(5);

	}

}

table->idx_get(0, 0)->get_TextFrame()->set_Text(u"00");
table->idx_get(0, 1)->get_TextFrame()->set_Text(u"01");
table->idx_get(0, 2)->get_TextFrame()->set_Text(u"02");
table->idx_get(0, 3)->get_TextFrame()->set_Text(u"03");
table->idx_get(1, 0)->get_TextFrame()->set_Text(u"10");
table->idx_get(2, 0)->get_TextFrame()->set_Text(u"20");
table->idx_get(1, 1)->get_TextFrame()->set_Text(u"11");
table->idx_get(2, 1)->get_TextFrame()->set_Text(u"21");

//AddClone adds a row at the end of the table
table->get_Rows()->AddClone(table->get_Rows()->idx_get(0), false);

//InsertClone adds a row at a specific position in a table
table->get_Rows()->InsertClone(2, table->get_Rows()->idx_get(0), false);

//AddClone adds a column at the end of the table
table->get_Columns()->AddClone(table->get_Columns()->idx_get(0), false);

//InsertClone adds a column at a specific position in a table
table->get_Columns()->InsertClone(2, table->get_Columns()->idx_get(0), false);


// Saves the presentation to disk
pres->Save(outPath, Aspose::Slides::Export::SaveFormat::Pptx);

Remove Row or Column from Table

  1. Create an instance of the Presentation class and load the presentation,
  2. Get a slide’s reference through its index.
  3. Define an array of columnWidth.
  4. Define an array of rowHeight.
  5. Add an ITable object to the slide through the AddTable() method.
  6. Remove the table row.
  7. Remove the table column.
  8. Save the modified presentation.

This C++ code shows you how to remove a row or column from a table:

// The path to the documents directory.
const String outPath = u"../out/RemovingRowColumn_out.pptx";

// Instantiates the Presentation class
SharedPtr<Presentation> pres = MakeObject<Presentation>();

// Accesses the first slide
SharedPtr<ISlide> islide = pres->get_Slides()->idx_get(0);

// Defines the columns with widths and rows with heights
System::ArrayPtr<double> dblCols = System::MakeObject<System::Array<double>>(4, 70);
System::ArrayPtr<double> dblRows = System::MakeObject<System::Array<double>>(4, 70);

// Adds a table shape to the slide
SharedPtr<ITable> table = islide->get_Shapes()->AddTable(100, 50, dblCols, dblRows);

table->get_Rows()->RemoveAt(1, false);
table->get_Columns()->RemoveAt(1, false);


// Merges cells (1, 1) x (2, 1)
table->MergeCells(table->idx_get(1, 1), table->idx_get(2, 1), false);

// Merges cells (1, 2) x (2, 2)
table->MergeCells(table->idx_get(1, 2), table->idx_get(2, 2), false);


// Saves the presentation to disk
pres->Save(outPath, Aspose::Slides::Export::SaveFormat::Pptx);

Set Text Formatting on Table Row Level

  1. Create an instance of the Presentation class and load the presentation,
  2. Get a slide’s reference through its index.
  3. Access the relevant ITable object from the slide.
  4. Set the first-row cells' set_FontHeight().
  5. Set the first-row cells' set_Alignment() and set_MarginRight().
  6. Set the second-row cells' set_TextVerticalType().
  7. Save the modified presentation.

This C++ code demonstrates the operation.

// Creates an instance of the Presentation class
auto presentation = System::MakeObject<Presentation>();

auto slide = presentation->get_Slides()->idx_get(0);

auto someTable = System::AsCast<ITable>(presentation->get_Slides()->idx_get(0)->get_Shapes()->idx_get(0));
// Let's assume that the first shape on the first slide is a table
// Sets first row cells' font height
auto portionFormat = System::MakeObject<PortionFormat>();
portionFormat->set_FontHeight(25.0f);
someTable->get_Rows()->idx_get(0)->SetTextFormat(portionFormat);

// Sets the first row cells' text alignment and right margin
auto paragraphFormat = System::MakeObject<ParagraphFormat>();
paragraphFormat->set_Alignment(TextAlignment::Right);
paragraphFormat->set_MarginRight(20.0f);
someTable->get_Rows()->idx_get(0)->SetTextFormat(paragraphFormat);

// Sets the second row cells' text vertical type
auto textFrameFormat = System::MakeObject<TextFrameFormat>();
textFrameFormat->set_TextVerticalType(TextVerticalType::Vertical);
someTable->get_Rows()->idx_get(1)->SetTextFormat(textFrameFormat);

// Saves the presentation to disk
presentation->Save(u"result.pptx", SaveFormat::Pptx);

Set Text Formatting on Table Column Level

  1. Create an instance of the Presentation class and load the presentation,
  2. Get a slide’s reference through its index.
  3. Access the relevant ITable object from the slide.
  4. Set the first-column cells' set_FontHeight().
  5. Set the first-column cells' set_Alignment() and set_MarginRight().
  6. Set the second-column cells' set_TextVerticalType().
  7. Save the modified presentation.

This C++ code demonstrates the operation:

// Creates an instance of the Presentation class
auto pres = System::MakeObject<Presentation>();

auto slide = pres->get_Slides()->idx_get(0);

auto someTable = System::AsCast<ITable>(pres->get_Slides()->idx_get(0)->get_Shapes()->idx_get(0));
// Let's assume that the first shape on the first slide is a table

// Sets the first column cells' font height
auto portionFormat = System::MakeObject<PortionFormat>();
portionFormat->set_FontHeight(25.0f);
someTable->get_Columns()->idx_get(0)->SetTextFormat(portionFormat);

// Sets the first column cells' text alignment and right margin in one call
auto paragraphFormat = System::MakeObject<ParagraphFormat>();
paragraphFormat->set_Alignment(TextAlignment::Right);
paragraphFormat->set_MarginRight(20.0f);
someTable->get_Columns()->idx_get(0)->SetTextFormat(paragraphFormat);

// Sets the second column cells' text vertical type
auto textFrameFormat = System::MakeObject<TextFrameFormat>();
textFrameFormat->set_TextVerticalType(TextVerticalType::Vertical);
someTable->get_Columns()->idx_get(1)->SetTextFormat(textFrameFormat);

pres->Save(u"result.pptx", SaveFormat::Pptx);

Get Table Style Properties

Aspose.Slides allows you to retrieve the style properties for a table so that you can use those details for another table or somewhere else. This C++ code shows you how to get the style properties from a table preset style:

auto pres = System::MakeObject<Presentation>();
auto shapes = pres->get_Slide(0)->get_Shapes();
auto table = System::ExplicitCast<ITable>(shapes->AddTable(10, 10, System::MakeArray<double>({100, 150}), System::MakeArray<double>({5, 5, 5})));

table->set_StylePreset(TableStylePreset::DarkStyle1);
pres->Save(u"table.pptx", SaveFormat::Pptx);
