Manage Rows and Columns

To allow you to manage a table’s rows and columns in a PowerPoint presentation, Aspose.Slides provides the Table class, ITable interface, and many other types.

Set First Row as Header

  1. Create an instance of the Presentation class and load the presentation.
  2. Get a slide’s reference through its index.
  3. Create an ITable object and set it to null.
  4. Iterate through all IShape objects to find the relevant table.
  5. Set the table’s first row as its header.

This PHP code shows you how to set a table’s first row as its header:

  # Instantiates the Presentation class
  $pres = new Presentation("table.pptx");
  try {
    # Accesses the first slide
    $sld = $pres->getSlides()->get_Item(0);
    # Initializes the null TableEx
    $tbl = null;
    # Iterates through the shapes and sets a reference to the table
    foreach($sld->getShapes() as $shp) {
      if (java_instanceof($shp, new JavaClass("com.aspose.slides.Table"))) {
        $tbl = $shp;
        # Sets the first row of a table as its header
        $tbl->setFirstRow(true);
      }
    }
    # Saves the presentation to disk
    $pres->save("pres.pptx", SaveFormat::Pptx);
  } finally {
    if (!java_is_null($pres)) {
      $pres->dispose();
    }
  }

Clone Table’s Row or Column

  1. Create an instance of the Presentation class and load the presentation,
  2. Get a slide’s reference through its index.
  3. Define an array of columnWidth.
  4. Define an array of rowHeight.
  5. Add an ITable object to the slide through the addTable method.
  6. Clone the table row.
  7. Clone the table column.
  8. Save the modified presentation.

This PHP code shows you how to clone a PowerPoint table’s row or column:

  # Instantiates the Presentation class
  $pres = new Presentation("Test.pptx");
  try {
    # Accesses the first slide
    $sld = $pres->getSlides()->get_Item(0);
    # Defines columns with widths and rows with heights
    $dblCols = array(50, 50, 50 );
    $dblRows = array(50, 30, 30, 30, 30 );
    # Adds a table shape to slide
    $table = $sld->getShapes()->addTable(100, 50, $dblCols, $dblRows);
    # Adds some text to the row 1 cell 1
    $table->get_Item(0, 0)->getTextFrame()->setText("Row 1 Cell 1");
    # Adds some text to the row 1 cell 2
    $table->get_Item(1, 0)->getTextFrame()->setText("Row 1 Cell 2");
    # Clones Row 1 at end of table
    $table->getRows()->addClone($table->getRows()->get_Item(0), false);
    # Adds some text to the row 2 cell 1
    $table->get_Item(0, 1)->getTextFrame()->setText("Row 2 Cell 1");
    # Adds some text to the row 2 cell 2
    $table->get_Item(1, 1)->getTextFrame()->setText("Row 2 Cell 2");
    # Clones Row 2 as 4th row of table
    $table->getRows()->insertClone(3, $table->getRows()->get_Item(1), false);
    # Clones first column at the end
    $table->getColumns()->addClone($table->getColumns()->get_Item(0), false);
    # Clones 2nd column at 4th column index
    $table->getColumns()->insertClone(3, $table->getColumns()->get_Item(1), false);
    # Saves the presentation to disk
    $pres->save("table_out.pptx", SaveFormat::Pptx);
  } finally {
    if (!java_is_null($pres)) {
      $pres->dispose();
    }
  }

Remove Row or Column from Table

  1. Create an instance of the Presentation class and load the presentation,
  2. Get a slide’s reference through its index.
  3. Define an array of columnWidth.
  4. Define an array of rowHeight.
  5. Add an ITable object to the slide through the addTable method.
  6. Remove the table row.
  7. Remove the table column.
  8. Save the modified presentation.

This PHP code shows you how to remove a row or column from a table:

  $pres = new Presentation();
  try {
    $slide = $pres->getSlides()->get_Item(0);
    $colWidth = array(100, 50, 30 );
    $rowHeight = array(30, 50, 30 );
    $table = $slide->getShapes()->addTable(100, 100, $colWidth, $rowHeight);
    $table->getRows()->removeAt(1, false);
    $table->getColumns()->removeAt(1, false);
    $pres->save("TestTable_out.pptx", SaveFormat::Pptx);
  } finally {
    if (!java_is_null($pres)) {
      $pres->dispose();
    }
  }

Set Text Formatting on Table Row Level

  1. Create an instance of the Presentation class and load the presentation,
  2. Get a slide’s reference through its index.
  3. Access the relevant ITable object from the slide.
  4. Set the first-row cells' setFontHeight(float value).
  5. Set the first-row cells' setAlignment(int value) and setMarginRight(float value).
  6. Set the second-row cells' setTextVerticalType(byte value).
  7. Save the modified presentation.

This PHP code demonstrates the operation.

  # Creates an instance of the Presentation class
  $pres = new Presentation();
  try {
    # Let's assume that the first shape on the first slide is a table
    $someTable = $pres->getSlides()->get_Item(0)->getShapes()->get_Item(0);
    # Sets first row cells' font height
    $portionFormat = new PortionFormat();
    $portionFormat::setFontHeight(25);
    $someTable->getRows()->get_Item(0)->setTextFormat($portionFormat);
    # Sets the first row cells' text alignment and right margin
    $paragraphFormat = new ParagraphFormat();
    $paragraphFormat::setAlignment(TextAlignment->Right);
    $paragraphFormat::setMarginRight(20);
    $someTable->getRows()->get_Item(0)->setTextFormat($paragraphFormat);
    # Sets the second row cells' text vertical type
    $textFrameFormat = new TextFrameFormat();
    $textFrameFormat::setTextVerticalType(TextVerticalType::Vertical);
    $someTable->getRows()->get_Item(1)->setTextFormat($textFrameFormat);
    # Saves the presentation to disk
    $pres->save("result.pptx", SaveFormat::Pptx);
  } finally {
    if (!java_is_null($pres)) {
      $pres->dispose();
    }
  }

Set Text Formatting on Table Column Level

  1. Create an instance of the Presentation class and load the presentation,
  2. Get a slide’s reference through its index.
  3. Access the relevant ITable object from the slide.
  4. Set the first-column cells' setFontHeight(float value).
  5. Set the first-column cells' setAlignment(int value) and setMarginRight(float value).
  6. Set the second-column cells' setTextVerticalType(byte value).
  7. Save the modified presentation.

This PHP code demonstrates the operation:

  # Creates an instance of the Presentation class
  $pres = new Presentation();
  try {
    # Let's assume that the first shape on the first slide is a table
    $someTable = $pres->getSlides()->get_Item(0)->getShapes()->get_Item(0);
    # Sets the first column cells' font height
    $portionFormat = new PortionFormat();
    $portionFormat::setFontHeight(25);
    $someTable->getColumns()->get_Item(0)->setTextFormat($portionFormat);
    # Sets the first column cells' text alignment and right margin in one call
    $paragraphFormat = new ParagraphFormat();
    $paragraphFormat::setAlignment(TextAlignment->Right);
    $paragraphFormat::setMarginRight(20);
    $someTable->getColumns()->get_Item(0)->setTextFormat($paragraphFormat);
    # Sets the second column cells' text vertical type
    $textFrameFormat = new TextFrameFormat();
    $textFrameFormat::setTextVerticalType(TextVerticalType::Vertical);
    $someTable->getColumns()->get_Item(1)->setTextFormat($textFrameFormat);
    $pres->save("result.pptx", SaveFormat::Pptx);
  } finally {
    if (!java_is_null($pres)) {
      $pres->dispose();
    }
  }

Get Table Style Properties

Aspose.Slides allows you to retrieve the style properties for a table so that you can use those details for another table or somewhere else. This PHP code shows you how to get the style properties from a table preset style:

  $pres = new Presentation();
  try {
    $table = $pres->getSlides()->get_Item(0)->getShapes()->addTable(10, 10, array(100, 150 ), array(5, 5, 5 ));
    $table->setStylePreset(TableStylePreset->DarkStyle1);// change the default style preset theme

    $pres->save("table.pptx", SaveFormat::Pptx);
  } finally {
    if (!java_is_null($pres)) {
      $pres->dispose();
    }
  }
