Apply Shape Effects in Presentations Using PHP

While effects in PowerPoint can be used to make a shape stand out, they differ from fills or outlines. Using PowerPoint effects, you can create convincing reflections on a shape, spread a shape’s glow, etc.

• PowerPoint provides six effects that can be applied to shapes. You can apply one or more effects to a shape.

• Some combinations of effects look better than others. For this reason, PowerPoint options under Preset. The Preset options are essentially a known good-looking combination of two or more effects. This way, by selecting a preset, you won’t have to waste time testing or combining different effects to find a nice combination.

Aspose.Slides provides properties and methods under the EffectFormat class that allow you to apply the same effects to shapes in PowerPoint presentations.

Apply a Shadow Effect

This PHP code shows you how to apply the outer shadow effect (OuterShadowEffect) to a rectangle:

  $pres = new Presentation();
  try {
    $shape = $pres->getSlides()->get_Item(0)->getShapes()->addAutoShape(ShapeType::RoundCornerRectangle, 20, 20, 200, 150);
    $shape->getEffectFormat()->enableOuterShadowEffect();
    $shape->getEffectFormat()->getOuterShadowEffect()->getShadowColor()->setColor(java("java.awt.Color")->DARK_GRAY);
    $shape->getEffectFormat()->getOuterShadowEffect()->setDistance(10);
    $shape->getEffectFormat()->getOuterShadowEffect()->setDirection(45);
    $pres->save("output.pptx", SaveFormat::Pptx);
  } finally {
    if (!java_is_null($pres)) {
      $pres->dispose();
    }
  }

Apply a Reflection Effect

This PHP code shows you how to apply the reflection effect to a shape:

  $pres = new Presentation();
  try {
    $shape = $pres->getSlides()->get_Item(0)->getShapes()->addAutoShape(ShapeType::RoundCornerRectangle, 20, 20, 200, 150);
    $shape->getEffectFormat()->enableReflectionEffect();
    $shape->getEffectFormat()->getReflectionEffect()->setRectangleAlign(RectangleAlignment->Bottom);
    $shape->getEffectFormat()->getReflectionEffect()->setDirection(90);
    $shape->getEffectFormat()->getReflectionEffect()->setDistance(55);
    $shape->getEffectFormat()->getReflectionEffect()->setBlurRadius(4);
    $pres->save("reflection.pptx", SaveFormat::Pptx);
  } finally {
    if (!java_is_null($pres)) {
      $pres->dispose();
    }
  }

Apply a Glow Effect

This PHP code shows you how to apply the glow effect to a shape:

  $pres = new Presentation();
  try {
    $shape = $pres->getSlides()->get_Item(0)->getShapes()->addAutoShape(ShapeType::RoundCornerRectangle, 20, 20, 200, 150);
    $shape->getEffectFormat()->enableGlowEffect();
    $shape->getEffectFormat()->getGlowEffect()->getColor()->setColor(java("java.awt.Color")->MAGENTA);
    $shape->getEffectFormat()->getGlowEffect()->setRadius(15);
    $pres->save("glow.pptx", SaveFormat::Pptx);
  } finally {
    if (!java_is_null($pres)) {
      $pres->dispose();
    }
  }

Apply a Soft Edges Effect

This PHP code shows you how to apply the soft edges to a shape:

  $pres = new Presentation();
  try {
    $shape = $pres->getSlides()->get_Item(0)->getShapes()->addAutoShape(ShapeType::RoundCornerRectangle, 20, 20, 200, 150);
    $shape->getEffectFormat()->enableSoftEdgeEffect();
    $shape->getEffectFormat()->getSoftEdgeEffect()->setRadius(15);
    $pres->save("softEdges.pptx", SaveFormat::Pptx);
  } finally {
    if (!java_is_null($pres)) {
      $pres->dispose();
    }
  }

FAQ

Can I apply multiple effects to the same shape?

Yes, you can combine different effects, such as shadow, reflection, and glow, on a single shape to create a more dynamic appearance.

What shapes can I apply effects to?

You can apply effects to various shapes, including autoshapes, charts, tables, pictures, SmartArt objects, OLE objects, and more.

Can I apply effects to grouped shapes?

Yes, you can apply effects to grouped shapes. The effect will apply to the entire group.
