Create Transparent Image of Excel Worksheet with C++

Sometimes, you need to generate the image of your worksheet as a transparent image. You want to apply transparency to all cells which have no fill colors. Aspose.Cells provides the ImageOrPrintOptions.GetTransparent() property to apply transparency to the worksheet image. When this property is false, then cells with no fill colors are drawn with white color and when it is true, cells with no fill colors are drawn transparent.

In the following worksheet image, transparency has not been applied. The cells with no fill colors are drawn white.

Output without transparency: the cell background is white

While, in the following worksheet image, transparency has been applied. The cells with no fill colors are transparent.

Output with transparency enabled

The following sample code generates a transparent image from an Excel worksheet.

#include <iostream>
#include "Aspose.Cells.h"
using namespace Aspose::Cells;

int main()
{
    Aspose::Cells::Startup();

    // Source directory path
    U16String sourceDir = u"..\\Data\\01_SourceDirectory\\";

    // Output directory path
    U16String outputDir = u"..\\Data\\02_OutputDirectory\\";

    // Create workbook object from source file
    Workbook workbook(sourceDir + u"sampleCreateTransparentImage.xlsx");

    // Apply different image or print options
    ImageOrPrintOptions imgOption;
    imgOption.SetImageType(static_cast<ImageType>(5)); // Png
    imgOption.SetHorizontalResolution(200);
    imgOption.SetVerticalResolution(200);
    imgOption.SetOnePagePerSheet(true);

    // Apply transparency to the output image
    imgOption.SetTransparent(true);

    // Create image after applying image or print options
    SheetRender sr(workbook.GetWorksheets().Get(0), imgOption);
    sr.ToImage(0, outputDir + u"outputCreateTransparentImage.png");

    std::cout << "Image created successfully!" << std::endl;

    Aspose::Cells::Cleanup();
}
